Bigger in every way a mighy powerful chassis. Modular design flexiblity for any configuration. Hot swappable drives.spacious for multiple and bigger components.Seamlessly supporting E-ATX motherboards.RGB lighting sync front panel addressable RGB.
Tempered Glass on the Front, and Left Side. E-ATX ,ATX Full Tower Gaming Computer Case
FLEXIBILITY FOR ANY CONFIGURATION
HOT SWAPPABLE DRIVES
for replacement or addition of storage without shutting down the system
SPACIOUS FOR MULTIPLE AND BIGGER COMPONENTS
(D) 471 x (W) 285 x (H) 513mm
EASIER BUILT PROCESS
EFFORTLESS CABLE MANAGEMENT
Extension bar (optional) enables support for the rog dominus extreme
RGB LIGHTING SYNCH
FRONT PANEL ADDRESSABLE RGB
Built-in rgb effect controlled by the front panel m|c buttons to synch with the motherboard, switch to the 8th mode
make sure to connect the 3-pin header of the controller to the 3-pin header on the motherboard. do not connect it to the 4-pin header or unrecoverable damages will occur.
EXQUISITE ALUMINUM EXTERIOR
I/O ports panel front panel right side case feet
PUSH AND HOLD TO UNLOCK THE TOP PANEL
screw-free, quick and easy
UPGRADED COOLING SUPPORT
Stronger airflow support for an additional 120mm fan at the rear
Enough room for a thick radiator at the bottom even when mounting dual gpu or vertical gpu
MULTIPLE TYPE OF PORTS TO SATISFY ANY NEED
4 x usb3.0 + 1 x type c + m|c rgb control buttons
2 x usb3.0 at top and bottom to catter to different usage scenarios
MORE FLEXIBILITY FOR GPU CONFIGURATION
8 slots to support dual gpu or vertically mount gpu
Supporting high-end gpus up to 169mm tall
VERTICAL GPU HOLDER
OPTIMIZED STORAGE LAYOUT
Interchangeable, more options for customisation possibility
THE HOT SWAPPABLE DRIVE BAYS
OFFERS ROOM FOR 4 DRIVES
3 INSIDE THE DRIVE PANEL BEHIND THE MOTHERBOARD
3 ON THE MOUNTING BRACKET BESIDE THE MOTHERBOARD
EACH SECTION IS REPLACABLE WITH 120MM FANS
O11D DISTRO-PLATE G1 DESIGNED BY EKWB
Multiple inlet and outlet ports
simplifies the water-cooling build process
argb lighting effect
come with a powerful ddc3.1 pwm water pump
In the condition of using the included riser cable (PCIE3.0) of the vertical GPU kit with a PCIE 4.0 motherboard and a PCIE 4.0 GPU, please follow bellow steps to set up your BIOS to make it compatible.
- Make sure that your motherboard BIOS is the latest version. If not, recommend to update to the latest version.
- Install your GPU directly to the motherboard and start.
- Enter your BIOS, set the PCIE slot from “Auto” to “Gen 3”. (Example photo as below, for more please read the manual of your motherboard)
- Save your settings and turn off the system
- 5. Install the PCIE 3.0 riser cable to the motherboard and the GPU, the system would be able to work.
German Engineering Approved
The O11 Dynamic series from LIAN LI is developed in collaboration with DER8AUR, a world-renowned German overclocking, water cooling, and gaming evangelist. Always looking for ways to improve computer design and performance, DER8AUER volunteered his time to review and test the design concepts of the O11D series.
Starting with the first O11 Dynamic and up until the most recent models of the O11D series, LIAN LI appreciates the input from DER8AUER which helped make the O11D series exceptional cases, especially in terms of custom water cooling compatibility, ease of build, and features offered. As a result, DER8AUER’s seal of approval is elegantly displayed beside the LIAN LI logo, standing as a statement of quality and reliability.
|Dimensions||(D) 471 x (W) 285 x (H) 513 mm|
|Motherboard||E-ATX/ATX/M-ATX/ITX (need to purchase an extension panel for EEB motherboards)|
|PSU||220 mm (max 280mm)|
|Materials||1.0 mm ALUMINUM EXTERIOR
4.0 mm TEMPERED GLASS LEFT SIDE AND FRONT PANELS
1.0 mm SPCC INTERIOR
|Fan Support||3 X 120 mm (side) + 1 X 120 mm (rear) + 3 X 120 mm/2 x 140 mm (base) + 3 X 120 mm/2 x 140 mm (top) (Optional)|
|GPU LENGTH||446 mm|
|CPU CLEARANCE||167 mm|
|Drive||10 X 2.5” SSD or 6 X 2.5” SSD + 4 X 3.5” HDD|
|I/O Ports||4 X USB 3.0 (2 on the front, 2 at the front case feet), 1 X USB 3.1 TYPE-C, 1 X HD AUDIO|
|Dust Filters||1 X TOP, 1 X BOTTOM, 2 X SIDE|
